PRIMALKYD ANTI CORROSIVE ALKED PRIMER A high quality alkyd based primer, with excellent surface adhesion on steel, containing high quality zinc phosphate and red iron oxide anticorrosive pigments A high quality alkyd based primer, with excellent surface adhesion on steel, containing high quality zinc phosphate and red iron oxide anticorrosive pigments
Properties and Areas of Use
-Tough hard wearing film.
-Low odor and excellent application properties.
-Excellent corrosion resistance.
-Excellent flow and opacity.
-Used as a primer on steel in an anticorrosion alkyd system.
-Used also as an anticorrosive primer on galvanized steel and aluminum over a suitable washing primer.
Technical Coating Data @ 25 °C
Color Range Red, Grey, Beige & Black
Solids Content (By Volume) 55 ± 2% depending on color
Dry Film Thickness Range 25-100 µm
Theoretical Spreading Rate 11 m² / L @ 50 microns DFT
(loss factors will apply in practice)
Surface Dry 2 h
Recoat Interval 16 hours minimum
maximum, several months (after proper
surface cleaning and preparation)
Flash Point 38°C
Shelf Life 12 months (stored in a cool dry place)
VOC 290 g/L
Mixing Ratio Single Pack
Film Thickness and Spreading Rate :
Minimum Maximum Typical
Film thickness, dry (µm) 25 100 50
Film Thickness, wet(µm) 45 182 91
Theoretical Spreading Rate (m2/L) 22 5.5 11
Suitable Surfaces :
– Steel and non-ferrous metals properly blast cleaned to SIS-Sa 21/2 minimum
-Substrates must be free of contamination, dust, and efflorescence
-Previously gloss painted surfaces should be thoroughly abraded or sand blasted before application.
Bare Steel :
Cleanliness: Blast – cleaning to Sa2 1/2 (ISO-8501-1:2007). Power tool cleaning to min. St2(ISO 8501-1:2007) may be acceptable, subject to exposure conditions.
Shop primed Steel :
Clean, dry and undamaged approved shop primer.
Coated Surfaces :
Clean, dry and undamaged compatible primer. For aluminum substrates, thorough washing and sweeping with a nonmetallic blast medium is required.
Application Conditions :
Substrate temperature should be 10C or above for application and during cure, and a
minimum of 3C above the dew point. Adequate dry air ventilation is recommended for
Application Information :
Thinning should only take place after the material has been thoroughly mixed.
Brush and Roller :
Thin if required with 0-5% COLORAMA Thinner 906 or 921.
Conventional Air Spraying :
– Thin with 5-15% COLORAMA Thinner 906 or 921, as required
-Tip size – 2.0 mm
-Tip pressure – 60 psi (0. 4Mpa) approximately
Airless Spraying :
-Thin with 0-10% COLORAMA Thinner 906 or 921, as required.
-Tip size – 13 thou (0.33mm) approximately
-Tip pressure – 1700 psi (12Mpa) approximately
Cleaning Thinner :
Equipment should be cleaned immediately Auer use with COLORAMA Thinner 906 or 921.
Drying time :
Drying times are affected by air ventilation, temperature, film thickness and number of
Substrate Temp. 10° C 25° C 40° C
Surface Dry 3 h 2 h 1 h
Through Dry 16 h 6 h 3 h
Dry to recoat, minimum 24 h 16 h 10 h
The given data serve as guideline only. The actual drying time differs according to film thickness, ventilation, humidity and underlying paint system.
Keep the containers in a dry, cool, well ventilated space and away from source of heat and ignition. Containers must be kept tightly closed.
Handle with care. Stir well before use.
Packing Size : 0.8 Kg, 3 Kg & 25 Kg
Summary Safety Information :
-Avoid inhalation of spray mist and skin contact by the use of masks, gloves
and other personal protection. Eyes should be cautiously washed with
water or proprietary wash, and medical attention obtained. Skin should be
thoroughly washed using a cleanser and soap and water.
-Product is flammable
-No sparks or flames
PRIMALKYD ANTI CORROSIVE ALKED PRIMER
